ComNet FVTXA2C1M Audio Extender Transmitter, 1.10", 5.30"

ComNet FVTXA2C1M Audio Extender Transmitter

The ComNet™ FVT/FVRXA2C1 series audio multiplexer provides the transmission of two bi-directional audio signals and one bi-directional contact closure over one multimode or single mode optical fiber. The modules use 24-bit 96kHz sample rate digital encoding for superior transmission of balanced line-level audio. Plug-and-play design ensures ease of installation and no electrical or optical adjustments are ever required. Bi-color (Red/Green) LED indicators confirm equipment operating status. Packaged in the exclusive ComNet ComFit housing, these units may be either wall or rack-mounted, or may be DIN-rail mounted by the addition of ComNet model DINBKT1 adaptor plate.

• Interchangeable between stand-alone or rack mount use ComFit


• Hot-swappable rack modules


• Transmits Balanced Line-Level Audio up to +6dBm


• Bi-color (Red/Green) LED status indicators confirm equipment operating status


• No In-field electrical or optical adjustments


• 600 Ohms Audio Input Impedance


• 24-Bit 96kHz Digitally Encoded Transmission


• 20Hz - 18kHz Audio Bandwidth


• Two bi-directional Audio Channels


• One bi-directional Contact Closure
