Omada Omada 24-Port Gigabit Stackable Lite L3 Managed Switch with 4 10G Slots

Omada Omada 24-Port Gigabit Stackable Lite L3 Managed Switch with 4 10G Slots

What This Product Does

Omada SG5428X is a dependable entry-level L3 switch tailored for the access layer, featuring L3 routing, fast 10 Gbps wired speeds, and stacking options. It includes 24 gigabit RJ45 ports, 4 10 Gbps SFP+ slots, physical stacking ability, and centralized management. Integrated with strong security and extensive management features, the SG5428X offers a reliable networking solution for SMEs, and ISPs.

High-speed Connectivity and Powerful Stacking

24 gigabit RJ45 ports and 4 10 Gbps SFP+ slots provide up to 128 Gbps switching capacity per unit. Up to 4 units of physical stacking empower the networking structure with built-in redundancy and performance.

Abundant Layer 3 Capabilities

Comes with abundant Layer 3 routing protocols that support a scalable network. Static Routing, RIP, OSPF, DHCP Server, and DHCP Relay are supported.

Highly Available

ERPS (Ethernet Ring Protection Switching) ensures rapid protection and recovery in ring topologies, which is essential for maintaining network uptime in medium business environments.

Enhanced Security Functions

Defend against a range of network threats with ACL support (IPv4 & IPv6), Dynamic ARP Inspection, IEEE 802.1X, MAB, Port Security, and Secure Shell.

Omada SDN

Integration into the Omada system brings centralized cloud management and a series of management features such as Zero-Touch Provisioning (ZTP). The Omada Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and gateways, providing 100% centralized cloud management-all controlled from a single interface.

Apart from the ability to be centrally managed via the web or the Omada app, SG5428X is also easy to manage via an intuitive web-based Graphical User Interface (GUI) or an industry-standard Command Line Interface (CLI). For both management methods, traffic is protected through SSL or SSH encryption. SNMP (v1/v2c/v3) and RMON support enable the switch to be polled for valuable status information and to send traps for abnormal events.

• Effectively increases available bandwidth on your network


• Lets you conveniently connect different networks to enable improved flexibility to your infrastructure


• Increases the stack bandwidth of the stack port further than that of a single port


• Features 24 networking ports to establish large network


• Supports layer 3 switching for enhanced performance and usability


• Rack mounting enables you to organize wires & secure cables for professional installation


• Management capability provides control over setup and configuration of your network


• Gigabit Ethernet port for ultra-fast network speeds


• Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
